Your CI pipeline builds the image. Then what? Someone runs kubectl apply. Or a Helm command buried in a deploy step. Or a script that SSHes into a bastion host. Three months later, nobody knows what's actually running in production — because the cluster state drifted from what's in Git.
GitOps fixes this by making Git the single source of truth for your cluster state. ArgoCD is the most widely adopted GitOps operator for Kubernetes, and for good reason: it's declarative, it auto-syncs, and it shows you exactly where reality diverges from intent.
This guide covers how to set it up properly — not the "hello world" version, but the version that survives real workloads.
GitOps is a deployment pattern with four principles, formalized by the OpenGitOps project:
The key shift: your CI pipeline no longer touches the cluster. It builds and pushes an image, then updates a manifest in Git. ArgoCD handles the rest.
The recommended installation uses the official Helm chart. For production, use the HA manifest:
kubectl create namespace argocd
kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/ha/install.yaml
Or via Helm for more control:
helm repo add argo https://argoproj.github.io/argo-helm
helm install argocd argo/argo-cd \
--namespace argocd \
--create-namespace \
--set server.extraArgs={--insecure} \
--set configs.params."server\.insecure"=true
The --insecure flag disables TLS on the ArgoCD server itself — you'll terminate TLS at your ingress controller, which is the standard pattern. Don't expose ArgoCD without TLS termination somewhere in the chain.
Get the initial admin password:
kubectl -n argocd get secret argocd-initial-admin-secret \
-o jsonpath="{.data.password}" | base64 -d
Change it immediately. Better yet, configure SSO via OIDC and disable the admin account entirely.
The most common mistake: putting application manifests in the same repo as the application code. This creates circular dependencies — a code change triggers CI, which updates manifests, which triggers CI again.
Use a dedicated config repository:
infra-gitops/
├── apps/
│ ├── api/
│ │ ├── base/
│ │ │ ├── deployment.yaml
│ │ │ ├── service.yaml
│ │ │ └── kustomization.yaml
│ │ └── overlays/
│ │ ├── staging/
│ │ │ ├── kustomization.yaml
│ │ │ └── replicas-patch.yaml
│ │ └── production/
│ │ ├── kustomization.yaml
│ │ └── replicas-patch.yaml
│ └── frontend/
│ ├── base/
│ └── overlays/
├── platform/
│ ├── cert-manager/
│ ├── ingress-nginx/
│ └── monitoring/
└── argocd/
├── projects.yaml
└── applicationsets.yaml
Key decisions:
apps/ from platform/ — platform components (cert-manager, ingress, monitoring) have different change cadences and approval requirements.An ArgoCD Application resource tells the controller what to deploy and where:
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
name: api-staging
namespace: argocd
spec:
project: default
source:
repoURL: https://github.com/your-org/infra-gitops.git
targetRevision: main
path: apps/api/overlays/staging
destination:
server: https://kubernetes.default.svc
namespace: api
syncPolicy:
automated:
prune: true
selfHeal: true
syncOptions:
- CreateNamespace=true
retry:
limit: 5
backoff:
duration: 5s
factor: 2
maxDuration: 3m
The critical settings:
automated.prune: true — removes resources that no longer exist in Git. Without this, deleted manifests leave orphaned resources in the cluster.automated.selfHeal: true — reverts manual kubectl changes. This is the whole point of GitOps — if someone patches something by hand, ArgoCD corrects it.retry — transient failures happen (API server overload, webhook timeouts). Exponential backoff prevents cascading retries.Managing individual Application resources per service per environment doesn't scale. ApplicationSets generate Applications from templates:
apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
name: apps
namespace: argocd
spec:
goTemplate: true
goTemplateOptions: ["missingkey=error"]
generators:
- git:
repoURL: https://github.com/your-org/infra-gitops.git
revision: main
directories:
- path: apps/*/overlays/*
template:
metadata:
name: '{{ index .path.segments 1 }}-{{ index .path.segments 3 }}'
spec:
project: default
source:
repoURL: https://github.com/your-org/infra-gitops.git
targetRevision: main
path: '{{ .path.path }}'
destination:
server: https://kubernetes.default.svc
namespace: '{{ index .path.segments 1 }}'
syncPolicy:
automated:
prune: true
selfHeal: true
This auto-discovers every apps/<service>/overlays/<env> directory and creates an Application for it. The goTemplate: true flag enables Go template syntax, which is the recommended mode for new ApplicationSets. Add a new service? Create the directory structure, push, done.
The one thing you cannot put in Git as-is: secrets. Three viable approaches:
Bitnami Sealed Secrets encrypts secrets client-side with a cluster-specific public key. Only the controller in the cluster can decrypt them.
kubeseal --format yaml < secret.yaml > sealed-secret.yaml
The sealed secret is safe to commit. Simple, but key rotation requires re-encrypting all secrets.
External Secrets Operator syncs secrets from external stores (AWS Secrets Manager, Vault, GCP Secret Manager) into Kubernetes secrets:
apiVersion: external-secrets.io/v1beta1
kind: ExternalSecret
metadata:
name: api-secrets
spec:
refreshInterval: 1h
secretStoreRef:
name: aws-secrets
kind: ClusterSecretStore
target:
name: api-secrets
data:
- secretKey: DATABASE_URL
remoteRef:
key: /production/api/database-url
This is the recommended approach for production. Secrets live in a dedicated secrets manager with its own access policies, audit logging, and rotation. The Kubernetes secret is derived, not source-of-truth.
Mozilla SOPS encrypts specific values in YAML files. ArgoCD has native SOPS support via a plugin. Good middle ground if you don't want to run an external secrets manager.
The promotion flow in GitOps:
api:sha-abc123 and pushes to registryAutomate step 2 with image updater or a simple CI job:
# In your app repo's CI pipeline (separate step after cloning infra-gitops)
- name: Update staging manifest
run: |
kustomize edit set image api=$IMAGE_TAG
git commit -am "chore: update api to $IMAGE_TAG"
git push
working-directory: infra-gitops/apps/api/overlays/staging
For production promotion, require a PR with approval. This gives you:
git revert the merge commitNot everything should sync immediately. ArgoCD supports sync windows to restrict when syncs happen:
apiVersion: argoproj.io/v1alpha1
kind: AppProject
metadata:
name: production
spec:
syncWindows:
- kind: allow
schedule: '0 8-17 * * 1-5'
duration: 9h
applications: ['*']
timeZone: Europe/Berlin
This restricts production syncs to business hours on weekdays — when someone is around to respond if things break.
For ordering dependencies (database migration before app deployment), use sync waves:
metadata:
annotations:
argocd.argoproj.io/sync-wave: "-1" # Runs before wave 0
Negative waves run first. Use wave -1 for migrations, wave 0 for the app, wave 1 for post-deploy checks.
ArgoCD exposes Prometheus metrics on :8082/metrics. The essential alerts:
argocd_app_info{sync_status="OutOfSync"} for more than 10 minutesargocd_app_info{health_status!="Healthy"} for more than 5 minutesargocd_app_sync_total{phase="Error"} rate increaseArgoCD also supports notifications via Slack, Teams, webhooks, or email. Configure at minimum: sync failed and health degraded notifications for production apps.
Putting secrets in Git unencrypted. Sounds obvious, but it happens. Use pre-commit hooks with gitleaks or detect-secrets to catch this before it lands.
Not enabling pruning. Without prune: true, deleting a manifest from Git leaves the resource running. You end up with ghost services that nobody maintains.
Ignoring resource hooks. ArgoCD respects resource hooks for pre-sync and post-sync jobs. Use PreSync hooks for database migrations instead of init containers — they're visible in the ArgoCD UI and have proper error handling.
Syncing everything to one namespace. Use the destination namespace in your Application to enforce namespace boundaries. Combine with ArgoCD projects to restrict which namespaces a team can deploy to.
GitOps with ArgoCD removes the "what's running in production?" guessing game. Every deployment is a Git commit. Every rollback is a revert. Every change is reviewable.
The setup investment is front-loaded — repository structure, ApplicationSets, secrets management, sync policies. Once it's running, deployments become boring. And boring deployments are exactly what you want.
Start with one service in staging. Get the feedback loop right. Then expand to production and add services incrementally. Don't try to migrate everything at once.
